Heavy Hex Nuts
DIN 6915, ASME B18.2.2
DIN 6915 heavy hex nuts are high-strength hexagon nuts with a larger width across flats than regular DIN 934 hexagon nuts. They are designed for structural bolting applications.
The DIN 6915-I/II standard requires that the bolt nut and washer be assembled and supplied by one manufacturer. All components should be identified with the manufacturer ID.
Heavy Hex Nuts
|
Technical Specification
|
|
|---|---|
|
Size:
|
M12 to M36 1/2″-2-1/2″ |
|
Grade:
|
Class 8, Class 10 ASTM A194 2H |
|
Materials:
|
Carbon Steel, Alloy Steel, MS, Copper, Brass & Stainless Steel (SS 304,SS 302, SS 316) |
|
Finish:
|
White Zinc Plated, Yellow Zinc Plated, Auto Black Plated, Chrome Plated & other as per customer requirement. |
